Lumishore - SUPRA THX1604 Thru-Hull Underwater Light - Dual Color, 20000 Fixture Lumens
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Ultra-Bright Dual-Color Thru-Hull Marine Lighting Solution
Lumishore's THX1604 offers an exceptional 20,000 verified fixture lumens and an ultra-wide 110° beam angle, delivering unparalleled illumination that creates a mesmerizing swimming pool effect in marine environments. Designed with versatility in mind, this full-powered thru-hull fixture combines two vibrant lighting options—blue and white—allowing you to switch colors, adjust brightness, fade seamlessly, or strobe at two speeds. The advanced SUPRA I-Connect Hub & Switch or a compatible MFD with the optional SUPRA Bridge ensures intuitive control and effortless operation.
Crafted with a flush-fit design and low-profile build, the THX1604 is ideal for transom, side, or bottom mounting. Its marine-grade aluminum bronze housing and multi-channel external driver make it a reliable and durable choice for all marine applications.
Key Specifications for Maximum Performance
- Available LED Colors: Dual Color (Blue & White)
- Verified Fixture Lumens (White): 20,000
- Beam Angle: 110° Ultra-Wide Coverage
- Number and Type of LEDs: White (48 x 10W), Blue (108 x 3W)
- LED Power (HiCOB Array): Yes
- Driver Type: Multi-Channel External Driver
- Typical LED Life: Over 50,000 hours
- Supply Voltage: 24 V DC
- Max Current Draw: 6.5A
- Housing Material: Marine-Grade Aluminum Bronze
Product Dimensions
- Approximate Shipping Weight: 9 lbs
- Fitting Size: Standard 1"
Highlights of the THX1604
- Dual-color functionality with blue and white lighting in a single fixture
- Ultra-bright output at 20,000 verified fixture lumens
- Wide 110° beam angle for exceptional illumination coverage
- Multiple user control options via SUPRA I-Connect Hub, MFD, or optional Lumishore Display
- Adjustable brightness, synchronized fade mode, and strobe options for enhanced customization
- Durable marine-grade aluminum bronze construction ensures longevity
- Flush-fit design for versatile mounting options on transoms, sides, or bottom surfaces
