Lumishore - ECLIPSE Flood Light 4" - Flush Mount, Black, 10/31V, 5500K, 1500 Lumens
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Powerful and Durable Flood Light for Marine Applications
The ECLIPSE 4" Flush Mount Flood Light is a high-performance lighting solution designed to withstand the challenges of marine environments. With its sleek, low-profile design and robust construction, it provides bright, wide-reaching illumination perfect for enhancing visibility onboard. Whether for deck lighting, cockpit use, or general security purposes, this flood light delivers exceptional performance while complementing the aesthetics of your vessel.
Constructed with marine-grade powder-coated aluminum housing and featuring an IP68 water ingress protection rating, it is built to endure harsh conditions. The advanced LED technology produces 1,500 fixture lumens of crisp, white light with a color temperature of 5500K, ensuring clarity and brightness. The oval beam angle of 70°–90° ensures extensive coverage in critical areas. Additionally, dimmable control comes as standard, offering flexibility for different lighting needs.
Technical Specifications
- Available Colors: White (5500K)
- Fixture Lumens: 1,500
- LED Type and Count: 3 x 10W White LEDs
- Control Options: On/Off switch (third-party supplied) or ECLIPSE Command Center
- Electrical Installation: Simple 2-wire connection
- Supply Voltage Range: 10.5–31 V DC
- Max Current Draw (12/24V): 1.7 A / 0.9 A
- Beam Angle: 70°–90° (oval beam)
- Water Ingress Protection Rating: IP68
Product Dimensions
- Width: 4" (10 cm)
- Weight: Approx. 1 lb
Finishes
- Marine-grade powder-coated aluminum housing
- Color Options: Black or White housing
Highlights
- Produces 1,500 fixture lumens of crisp, white light
- Wide-reaching oval beam (70°–90°) for extensive illumination
- Dimmable control for customizable lighting levels
- Low-profile design suitable for mounting on cabin tops, T-tops, arches, transoms, and radar pedestals
- IP68-rated for maximum protection in marine environments
- Built with durable, marine-grade powder-coated aluminum
