Lumishore - 4" Flood Light - 10.5-31VDC, White
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Advanced CRGBW Flood Lights for Marine Applications
The LUX Bracket Mount Flood Light is a game-changer in marine lighting, offering unparalleled performance and versatility. Engineered for deck, cockpit lighting, and general security applications, these lights provide a high-intensity, ultra-wide beam that ensures maximum illumination and even light diffusion. The innovative design combines warm and cold white, as well as red, green, and blue, in a single unit, allowing for an unmatched full-spectrum lighting experience.
These low-profile, articulating flood lights are built for exterior mounting on cabin tops, T-tops, arches, transoms, and radar pedestals, enhancing both functionality and aesthetics. Designed to endure the harshest marine environments, the unit features a marine-grade powder-coated aluminum housing and an IP68 water ingress protection rating for ultimate durability.
The LUX Flood Light is easily operable via a simple switch and offers optional integration with compatible MFDs and Lumishore Displays for seamless control.
Technical Specifications
- Available Colors: Tunable white color temperature (2700K to 6500K) and full-spectrum RGB
- Lumens: 2,360 total; 1,050 fixture lumens
- LED Configuration: Warm white, cold white, red, green, and blue (5-channel HICOB array)
- Typical LED Life: 50,000+ hours
- Beam Angle: 70° - 90° oval beam
- Housing Material: Powder-coated aluminum body with frosted lens
- Electrical Installation: Simple 3-wire connection
- Driver: Multi-channel internal driver
- Supply Voltage Range: 10.5—31 V DC
- Max Current Draw (12/24V): 1.7 A / 0.9 A
- Water Ingress Protection Rating: IP68
Product Dimensions
- Light Diameter: 4 inches (10 cm)
Highlights
- High-intensity 1,050 fixture lumens for superior illumination
- Full-color CRGBW with tunable white temperature from 2700K to 6500K
- Ultra-wide 70° - 90° beam angle with custom diffusion optics
- Durable powder-coated aluminum housing with IP68 rating
- Dimmable as standard and compatible with advanced integration options
- Ideal for marine applications, including decks, cockpits, and security
