Garmin STRIKER Vivid 5cv Ice Fishing Fishfinder Bundle, 5 in Display, GT8HW-IF CHIRP Traditional Sonar Transducer, Built-In Flasher, GPS, Quickdraw Contours, Lead Acid Battery, Carrying Case

Overview

The Garmin 010-02551-04 is a STRIKER Vivid 5cv portable fishfinder bundle built around a 5-inch color display (800 x 480) and CHIRP sonar, packaged for ice fishing with a carry bag and a rechargeable lead-acid battery. The display is IPX7-rated and the unit transmits at 500 W (RMS), which is plenty for clearly reading bottom and seeing fish and lure movement in typical freshwater depths.

This bundle includes the GT8HW-IF ice transducer for CHIRP traditional sonar, plus a built-in flasher view that makes it easy to track your jig and watch fish move in and out of the sonar beam. Integrated GPS handles waypoint marking and routes, and Quickdraw Contours lets you build your own contour maps with 1 ft lines and save large areas for repeat trips.

Key features

• 5-inch WVGA color display with 800 x 480 resolution
• IPX7 water rating for spray, snow, and quick washdowns
• 500 W (RMS) transmit power for strong target returns
• Built-in flasher view for real-time lure and fish tracking
• GT8HW-IF transducer included for high-wide CHIRP traditional sonar (150 to 240 kHz) with beam coverage up to 24 degrees
• Integrated GPS for waypoint marking, routes, and speed display
• Quickdraw Contours custom mapping with 1 ft contours and storage for up to 2 million acres
• Supports CHIRP (mid and high) and can run ClearVü (260/455/800 kHz) with a compatible transducer
• Low power draw at 12 V (0.40 A) to keep portable and small-boat power budgets in check

Installation and setup

For ice use, the portable kit keeps everything together: mount the display on the included tilt/swivel bracket, connect the power/data cable to the battery, and lower the GT8HW-IF transducer through the hole using the float so it hangs level. Once the transducer is steady, the flasher view and traditional sonar are quick to dial in for the depth you are fishing.

On a boat, the display can be hard-mounted using the included bracket hardware and powered from a 12 VDC circuit. The GT8HW-IF transducer is shaped for ice use; for transom, trolling motor, or in-hull installs, pairing the display with a compatible open-water transducer is the clean way to match your mounting location and sonar goals.

Compatibility and fit

The unit uses a single 4-pin transducer port, so it is important to match connector type when swapping transducers between seasons. GPS functions on this unit are focused on fishing workflow: marking spots, building routes, and showing speed. It does not add chartplotter cartography, so it is best used alongside your normal navigation setup if you are running inshore or offshore.

This bundle is a good match for anglers who want one screen that can move between hardwater season and small-boat fishing, and for anyone who prefers simple waypoint navigation with DIY depth mapping rather than preloaded charts.

What’s included

• STRIKER Vivid 5cv fishfinder
• GT8HW-IF transducer
• Power/data cable
• Tilt/swivel mount
• Mounting hardware
• Documentation
• Garmin bumper sticker
• Bag with handle
• Foam float
• Rechargeable lead-acid battery
• Battery charger
