SI-TEX - SAS-900 Class A AIS
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Unparalleled AIS Performance for Marine and Commercial Use
The Sitex SAS-900 Class A AIS is a top-tier AIS transceiver designed for commercial and military maritime operations. Engineered for reliability, it meets the highest international standards, including SOLAS, MED, FCC, and Inland Waterway certifications. Its robust IPx6 and IPx7-rated waterproof construction ensures seamless operation in the harshest environments. The SAS-900 integrates seamlessly with all bridge systems and features advanced Electronic Charts (C-Map) for high-performance navigation. Equipped with multi-lingual support, an intuitive user interface, and essential safety functionalities like MOB (Man Overboard) and SART (Search and Rescue Transponder) tracking, this transceiver offers unmatched efficiency and security on the water.
Superior Connectivity and System Integration
Designed for full interoperability, the SAS-900 supports both NMEA0183 and NMEA2000 standards, ensuring seamless communication with other onboard navigation and safety systems. The integrated WiFi feature enhances operational flexibility, allowing for remote connectivity and data access.
High-Definition Display with Advanced Charting
A large, high-resolution color screen enhances usability by displaying Electronic Chart overlays with AIS target tracking. This intuitive interface allows for efficient monitoring and control, ensuring real-time situational awareness.
Rugged and Reliable Construction
Built to withstand the demands of marine environments, the SAS-900 features integrated shock and vibration protection for continuous, long-term operation. Its weatherproof casing ensures durability, making it ideal for both commercial and navy applications.
Technical Specifications
- Power Supply: 12 to 24VDC
- Power Consumption: < 12W
- Weight: 1.5kg
Connectivity and Data Interfaces
- NMEA0183 (IEC61162-2) Bi-Directional Ports: 3
- NMEA0183 (IEC61162-1) Sensor Inputs: 3
- DGPS Correction Data Input: 1
- Alarm Relay Output: 1
- NMEA2000: 1
- WiFi: 802.11 b/g/n
- Pilot Port (Optional): 1
VHF Transceiver Performance
- Transmitter: 1
- Receivers: 3
- Frequency Range: 156.025MHz to 162.025MHz
- Output Power: 1W or 12.5W (automatic)
- Channel Bandwidth: 25kHz
- Modulation Mode: GMSK-TDMA
- Receiver Sensitivity: -107dBm @ 20% PER
GNSS Receiver Capabilities
- Channels: 72
- Supported Systems: GPS and GLONASS (Parallel Dual Mode Operation)
- Compliance: IEC61108-1
- GNSS Antenna: Supplied
Product Dimensions
- Dimensions: 152mm x 165mm x 111mm
Highlights
- Fully certified for international marine standards
- Waterproof (IPx6 & IPx7) and shock-resistant design
- High-performance Electronic Chart display with AIS overlay
- Integrated WiFi and multi-network connectivity
- MOB and SART alert tracking for enhanced safety
- Seamless interoperability with other bridge systems
What’s in the Box
- SAS-900 Class A AIS Transceiver
- Mounting bracket
- GNSS Antenna with cable
- 18-way data cable
- 14-way data cable
- Power cable
- Mounting hardware
- Documentation
The Sitex SAS-900 Class A AIS is the ultimate choice for professionals seeking reliability, precision, and safety in maritime navigation. Built for commercial, military, and inland waterway use, it ensures optimal performance and seamless integration with modern bridge systems.
