Michigan Wheel 10R16 3Bl Al Vortex (30-70 Hp) (992409)

The 10 X 16 A3R PROP Michigan Wheel Vortex is a high-performance aluminum boat propeller. The new 4-blade Vortex propellers are meant to enhance holeshots without compromising top-end speed. The redesigned, aggressive blade geometry combines with an additional cup for maximum acceleration and grip, while a smaller diameter aids in maintaining top-end speed.

Available in a variety of configurations (9.9 HP through V6/V8 Outboard & Sterndrive).

Additional features and Specifications:

• Aluminum design with high performance
• Outboards and inflatables both perform well.
• Powder coat finish in gloss black

• Engine Type: Honda, Mercury, Suzuki, Tohatsu, Yamaha (30-70)
• Number of splines: Determined by hub kit
• Hub kit: Required
• Manufacturer: Michigan Wheel Marine
• Exterior: Brushed

For applications:

JOHNSON, EVINRUDE:

1999 - 2005 40 HP 4-Stroke

1999 - 2005 50 HP 4-Stroke

FORCE, CHRYSLER, UNITED STATES MARINE:

1995 - 1998 40 HP

1995 - 1998 50 HP

From 1991 until 1995, a 70-horsepower engine was available.

1996 - 1998 75 HP

HONDA:

1991-1994 BF 35

1995 and newer BF 40

1991-1994 BF 45

1995 and newer BF 50 / 50A

2010 and newer BF 60 / 60A

MARINER, MERCURY:

1974 - 1976 40 HP (Model 402)

1974 - 1976 50 HP (Model 500)

1976, 60 HP (Mariner®).

1972 - 1976 65 HP (Model 650)

MARINER, MERCURY:

1999 - 2005 25 HP 4-Stroke/Bigfoot

1994 - 2002 30 HP 2-Stroke

1999 - 2005 30 HP 4-Stroke

1994 and newer 30 HP (Sea Pro/Marathon)

From 1984 through 1989, 35 HP was available.

1977 and 40 HP 2-Stroke (Includes Model 402)

1997 and newer 40 HP 4-Stroke (Not Bigfoot)

1977 and newer 40 HP (Sea Pro/Marathon)

1986 - 1989 45 HP

All Years 48 HP (Mariner®)

1977 and 50 HP 2-Stroke (Includes Model 500)

1995 and newer 50 HP 4-Stroke (Not Bigfoot)

1995 and newer 55 HP (Mercury/Sea Pro/Marathon)

1978 and newer 60 HP 2-Stroke

2001 and newer 60 HP 4-Stroke (Not Bigfoot)

70 HP (Model 700 included) till 1983

TOHATSU, NISSAN:

Thru 1984, 35 HP (35B Only)

40 HP (includes TLDI, 40C, M40D, and MD40) 1984 and after

MFS40 2015 and Up

50 HP (excluding 50C, which includes TLDI, M50D, and MD50) 1992 and after

MSF50 2015 and Up

BFT60 2014 and Up

YAMAHA:

T25 HP (2010 and after)

2001-2005 F30 4-Stroke; 2015 and Newer

40 HP (including 40C) 1984 and after

1999 and newer F40 4-Stroke

1995 - 2000 48 HP

1984 and newer 50 HP (Not T50)

1995 and newer F50 4-Stroke

From 1976 through 1995, the 55 HP was produced.

From 1976 through 1991, a 60-horsepower engine was available.

1999 and newer F60 4-Stroke

Standard 3 & 4-Blade

This product replaces:

• 14984012843
