Blue Sea Systems Circuit Breaker Panel Backlight System, 10 Position, 12/24V
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Overview
The Blue Sea Systems 8069 is a 10-position backlight system for compatible Blue Sea Systems circuit breaker panels. It runs on 12V or 24V DC systems, uses two 6 inch 18 AWG wire leads for connection, and is rated for a maximum of 24V DC.
This is a straightforward way to light panel labels so breaker positions stay readable when the cabin is dark, the helm is running at night, or the electrical panel sits in a lower compartment with limited ambient light. Reverse polarity protection is built in, which helps prevent damage if the supply leads are connected incorrectly during installation.
For boat owners updating a DC distribution panel, this part matters most when fit and wiring are the main questions. It is intended for Blue Sea Systems circuit breaker panels, so it should be matched to a panel layout that accepts this 10-position backlight format before ordering.
Key features
- 10-position backlighting layout for circuit breaker panel labels
- Built for use with compatible Blue Sea Systems circuit breaker panels
- Works with 12V and 24V DC electrical systems
- Two 6 inch 18 AWG wire leads for power connection
- Reverse polarity protection is built in
- Maximum voltage rating of 24V DC
Compatibility and fit
This unit is meant for Blue Sea Systems circuit breaker panels rather than as a universal panel light. The main fit check is panel compatibility and position count, since this version is laid out for 10 positions. On a boat with an existing Blue Sea panel, that makes it easier to confirm whether the backlight will line up with the breaker label area and connect without extra adaptation.
Installation and setup
Power is supplied through two 18 AWG leads, each 6 inches long, so installation is usually simplest when a 12V or 24V DC feed is already available close to the panel. Reverse polarity protection adds a useful margin during refit work, especially when access behind the panel is tight and wiring is being completed in place.
Because this is a panel component, it makes the most sense in installations where label visibility matters during night operation or low-light checks at the dock. That can include cruising boats, fishing boats, and sailboats with the DC panel mounted below deck or away from direct cabin lighting.
