Garmin BlueChart Coastal Chart, California to Mexico, 1-Foot Contours, Depth Range Shading, Shallow Water Shading

Overview

The Garmin BlueChart g3 HD HXUS021R is an electronic coastal chart region for California and Mexico that covers Point Arena to Puerto Vallarta, including Mendocino, San Francisco Bay, the Channel Islands, San Diego, and the Baja Peninsula, with general Mexican coast coverage that includes Mazatlan, Acapulco, and Salina Cruz.

Chart detail includes navigational aids, spot soundings, depth contours, tides and currents, and harbor and marina information. Depth Range Shading supports up to 10 depth ranges, and the chart includes up to 1-foot contours where the underlying data supports it, which helps when you are reading bottom structure and picking safer water around shoals and tight approaches.

Key features

• Coverage from Point Arena to Puerto Vallarta, including San Francisco Bay, the Channel Islands, San Diego, and the Baja Peninsula
• General coverage along the Mexican coast, including Mazatlan, Acapulco, and Salina Cruz
• Depth Range Shading for up to 10 depth ranges to make target depths easier to scan at a glance
• Up to 1-foot contours (where chart data supports it) for clearer bottom definition in ports, canals, and nearshore areas
• Shallow Water Shading supports user-defined depth highlighting to help spot skinny water
• Includes navigational aids, spot soundings, tides and currents, and detailed harbor and marina data

Variants

This chart region is offered as BlueChart g3 or BlueChart g3 Vision, and in either SD Card or Download format.

BlueChart g3 Vision adds premium viewing layers such as satellite imagery, aerial photographs, and 3D perspectives on compatible Garmin displays. The standard BlueChart g3 option focuses on the core chart presentation and its depth and shading tools.

• 010-C0722-20: BlueChart g3, SD Card. A physical microSD/SD chart card that stays in the plotter while you use the chart layer.
• 010-D0554-00: BlueChart g3, Download. Digital delivery that is installed using Garmin Express.
• 010-C0722-00: BlueChart g3 Vision, SD Card. Adds satellite and aerial layers plus 3D chart views when your plotter supports them.
• 010-D0481-00: BlueChart g3 Vision, Download. Vision features with digital delivery and installation through Garmin Express.

Compatibility and fit

These charts are intended for Garmin chartplotters and multifunction displays that support BlueChart g3 cartography. Confirm your unit supports this cartography and that it matches the format you plan to use, either a chart card slot for microSD/SD or support for chart downloads.

Installation and setup

For SD card versions, insert the chart card into the plotter and select the chart layer from the chart menu. Keep the card installed while navigating with that region.

For download versions, install the chart through Garmin Express, then access the region from your Garmin device once the installation is complete.

Use cases on board

This region is a practical fit for coastal cruising and fishing runs along California, the Channel Islands, and the Baja route, where depth range shading and tight contour detail can make planning and on-water decision-making easier near shore and around harbor entrances.
