FLIR Systems - M364C LR Dual Payload Thermal Camera No JCU 640 x 512 18D HFoV
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Advanced Marine Thermal Imaging with Multispectral Vision
The FLIR Systems M364C LR is a high-performance dual-payload thermal camera designed to provide superior situational awareness on the water. Featuring state-of-the-art thermal imaging combined with a high-definition low-light camera, this system is engineered for law enforcement, commercial mariners, and serious recreational boaters.
Equipped with FLIR Systems’ exclusive Color Thermal Vision™ (CTV) technology, the M364C LR overlays visible camera details onto thermal images, offering unparalleled clarity in navigation and target identification. Enhanced gyro-stabilization ensures a steady view, minimizing disruptions caused by vessel movement, while long-range zoom capabilities enable precise recognition of navigation aids and other vessels.
Cutting-Edge Thermal and Visible Imaging Technology
- FLIR Systems Color Thermal Vision™ (CTV): Integrates visible spectrum details with thermal imaging for enhanced identification.
- MSX® Technology: Multi-Spectral Dynamic Imaging sharpens thermal visuals with edge detail and texture from the visible spectrum.
- High-Definition Low-Light Camera: Captures detailed imagery in challenging lighting conditions.
- 30x Optical Zoom for Daylight Imaging: Ensures exceptional clarity and long-range visibility.
- Two-Axis Mechanical Stabilization: Eliminates the impact of pitch, yaw, and heave for a steady image.
Technical Specifications
- Thermal Sensor: 640 x 512 VOx Microbolometer
- Field of View (Thermal): 24° x 18°
- Image Processing: Proprietary Digital Detail Enhancement
- Zoom Capabilities:Thermal: 8x continuous E-Zoom
- Visible Light: 30x optical zoom, 12x E-Zoom
- Daylight Camera Sensor: 1/2.8” Exmor R CMOS
- Daylight Camera Resolution: Up to 1080/30p high-definition video
- Minimum Illumination: As low as 0.0008 lux for superior night vision
Durability and Environmental Protection
- Water Ingress Protection: IPX6-rated, capable of withstanding heavy seas and power jets of water
- Shock Resistance: 15g vertical, 9g horizontal impact protection
- Wind Tolerance: Operational up to 100 knots (115.2 MPH)
- Operating Temperature Range: -13°F to +131°F (-25°C to +55°C)
- Storage Temperature Range: -30°F to +158°F (-30°C to +70°C)
- Salt and Sand Resistance: Built to withstand marine environments with IEC60945 and Mil-Std-810E compliance
Connections and Output Options
- Video Output: HD-SDI lossless video and H.264 network video stream
- Analog Video Output: NTSC/PAL user-selectable
- Connector Types: BNC for analog video
What's Included in the Box
- FLIR M364C LR Camera
- Camera base seal and gasket
- RayNet-to-RJ45 adaptor cable (120 mm)
- Right-angled RayNet-to-RayNet cable (3 m)
- Right-angled BNC-to-BNC cable (3 m)
- Right-angled 3-pin power cable (3 m)
- Mounting riser
- Camera fixings (nuts, dome nuts, washers, threaded studs)
- Self-adhesive decals (for ball-down mounting)
- Documentation pack
The FLIR M364C LR is an indispensable tool for those requiring high-performance thermal imaging, low-light visibility, and advanced stabilization in demanding marine conditions.
