Brp 14.125X19 Stainless Steel 4 Blade Right Hand Prop Cyclone Tbx Hub (763942)

14.125X19 Stainless Steel 4 Blade Right Hand PROP CYCLONE TBX Hub (763942) is an excellent propeller for performance and power. It is a four-blade propeller made of premium quality stainless steel that rotates in the right-hand direction. It keeps compass headings and stays hooked up in big water when you need a propeller that can hold the course straight and true in all water conditions. It is specifically designed for heavy and twin-engine boats and runabouts. It is also equipped with the TBXTM with an interchangeable hub, which adds a new level of endurance and dependability by flexing and cushioning shock loads to safeguard the bottom unit drivetrain.

Key Features:

• Right-hand rotation direction
• Four-blade propeller
• TBXTM Hub System
• Offshore and runabout propeller with four blades for maximum performance
• RPMs are kept to a minimum, allowing the plane to stay on the plane.
• In all water conditions, it tracks true.
• It is recommended are runabouts, decks, flats/bays, multi-species (Aluminum only), and offshore boats.

Product Specifications

• SKU: 763942
• UPC: 824375031090
• Weight: 16.80 LBS
• PITCH: 19
• Rotation: Right
• Blades: 4BL
• Diameter: 14 1/8 inches

Engine Application

90-140 Horsepower V-6 Gearcase, 135-250 Horsepower V-6, 250-300 Horsepower V-8

V-6 Gearcase—90 hp (Evinrude E-TEC™)…2004-thru;
100 hp…2004-thru;
100 hp (Commercial)…1984-thru;
120 hp…1985;
130 hp…1995-96;
40 hp…1985;
140 hp (25”)…1989-thru V-6 —135 hp…2000-thru;
150 hp…1978-thru;
155 hp (Commercial)…1978-thru;
175 hp…1977-thru;
185 hp…1984-85;
200 hp…1976-thru;
225 hp…1986-thru;
235 hp…1978-85;
250 hp…2000-thru;
2.6L…1984-85 V-8—250 hp…1991-thru;
275 hp…1986-88;
300 hp…1988-95;
3.6L…1986-87

Attaching Hardware:H26

Omc Stern Drive, Omc Cobra, & Omc Model 800

3.0L…1990-93;
3.8L…1980-93;
4.3L…1985-93;
5.0L…1978-93;
5.0L…1978-93;
5.0L HO…1989-93;
5.0L (EFI)…1993;
5.7L…1978-93;
5.8L…1978-93;
5.8L (EFI)…1993;
7.4L…1987-93;
7.5L…1987-93;
454 King…1990-93;
502 King…1990-93;
3.2L Diesel…1992

Attaching Hardware:H83

Attaching Hardware

H26

Cotter pin (100/box):
Other: 354987
Cotter pin only (10/pack):
Sierra: 18-3741
Other: 306394
Nut, keeper & pin:
Sierra: 18-3708-1
Other: 398042
Nut, keeper & pin:
Quicksilver: 802126Q1
Spacer, nut, keeper & pin kit:
Sierra: 18-3715
Quicksilver: 802009Q1
Splined spacer washer (aft):
Sierra: 18-4231
Splined spacer, nut, keeper & pin kit:
Sierra: 18-3715
Thrust washer (forward) 1.004" I.D. 1990 & Earlier:
Sierra: 18-4223
Thrust washer (forward) 1.065" I.D. 1991 & Later:
Other: 3852020
Turbo brand for V-6 Evinrude ‘91 & newer VT-2 Evinrude Intruder or Johnson Fastrike 150 & 175 Shooter/Renegade thrust washer (forward) 4-blade 1991 and newer:
Other: 128740 or VT-3

H83

Prop nut (aft, small):
Other: 872179
Prop nut (forward, large):
Other: 3851335
Tool kit (for both props):
Other: 885195

This product replaces:

• BRP763942, 824375031090, 763942, 177232, BRP177232
