Lumishore ECLIPSE SNL100 Neon Flex Light, 1m, 12V, IP68, RGB

Overview

The Lumishore 010-04534-00 is a 1 m ECLIPSE Neon Flex SNL100 RGB strip light that creates a continuous line of color without visible LED dots. It runs on 12V DC only (10 to 15 V DC) and draws up to 0.5 A (6 W) for the full 1 m length, which keeps it straightforward to power from a typical onboard lighting circuit.

The strip is IP68-rated and fully encapsulated, which helps it handle washdowns, vibration, and saltwater exposure. With an illuminated cross section of 12.0 mm x 6.1 mm, it tucks neatly under gunwales, along steps, behind coamings, or in a cockpit recess where you want accent light without bulky fixtures.

RGB control is handled through an ECLIPSE Command Center, supporting on/off, dimming, and zone control, plus color selection and sound-to-light functionality when that feature is enabled in your system.

Key features

• 1 m RGB neon flex strip with 120 RGB LEDs per meter and a spot-free diffuser for a line of light that looks continuous
• 12V DC only (10 to 15 V DC) with up to 0.5 A draw for the 1 m run (6 W)
• IP68 ingress protection with construction that is fully encapsulated and potted; UV resistant and salt-spray tested
• Cut-to-length format in 25 mm steps, with sealing required before installation after trimming
• Simple 4-wire electrical installation; cable entry can be configured from the bottom or the side (fit and seal before installation)
• ECLIPSE Command Center control for on/off, dimming, zone control, color selection, and sound-to-light functionality
• Illuminated cross section of 12.0 mm x 6.1 mm; end cap dimensions of 14.0 mm x 8.0 mm for recess planning
• 3-year warranty

What's included

• 1 m Neon Flex SNL100 RGB strip light
• End sealing kit for cut-to-length installs

Installation and setup

Lay the strip out straight before cutting, mark the nearest cut point, and trim only at a marked cut location. After cutting, seal the new end before the strip goes on the boat, then mount it using stainless steel screw clips or a suitable channel that supports the strip without pinching it.

Handle it like a lighted extrusion rather than a rope light: side-bend only, avoid twisting, and keep bends gentle. The minimum bend radius is 120 mm in the vertical axis. The material is UV resistant, but avoid mounting where it will sit in strong direct sunlight.

It can be installed indoors, in partially covered areas, and in locations that get wet, but it is not intended to be permanently submerged.

Electrical and control integration

This strip is a 12V DC load with a 4-wire connection. For RGB operation it must be used with an ECLIPSE Command Center; it is not wired directly to a basic on/off switch.

When you are planning multiple runs, keep each lighting type on its own Command Center zone output, and note that a zone supports up to 20 m of Neon Flex.

Use cases on board

This setup makes sense for boats that already have an ECLIPSE Command Center and want a clean accent line in the cockpit, around seating bases, under gunwales, or along cabin features where you do not want individual point lights. It is also a good match for refits where space is tight and you need a slim profile that still looks finished once installed.

Maintenance and care

Rinse with fresh water after heavy salt exposure and clean with mild soap and a soft cloth. Periodically check mounting points, cable routing, and any sealed cut ends to make sure everything stays tight and watertight.
