Lumishore EOS-LUX Command Center, For Lumishore EOS/LUX, IP67, MFD Control
Got questions? Ask an expert!
Know someone who needs this?
Share it with your crew or mechanic.
Overview
The Lumishore 010-04360-00 is an EOS-LUX Command Center that manages Lumishore LUX above-water lights and SMX, THX, and TIX EOS underwater lighting systems from a compatible MFD, an optional EOS-LUX-SUPRA display, or Wi-Fi. It runs on 10.5 to 31 V DC (12/24 V systems) and draws up to 0.5 A, so it fits typical onboard DC power setups without being a heavy load.
This unit handles zone control and scene control, which is helpful when you want different lighting behavior at the transom, cockpit, hardtop, or along the deck. With compatible fixtures, it supports full-spectrum RGB control and tunable white color temperature from 2700K to 6500K. The housing is IP67-rated for washdowns, and it includes reverse-polarity protection, load-dump protection, and ISO 8846 ignition protection.
Key features
- 10.5 to 31 V DC input for 12 V and 24 V boats
- Max current draw up to 0.5 A
- IP67-rated enclosure for wet marine environments and washdowns
- Works with Lumishore LUX above-water lights and SMX, THX, and TIX EOS underwater lighting systems
- Control options: certified MFD integration, optional EOS-LUX-SUPRA display, and Wi-Fi control from a connected device
- Zone control and lighting scenes for grouping fixtures around the boat
- Supports RGB control and tunable white (2700K to 6500K) with compatible lights
- Built-in protection features: reverse polarity, load dump, and ISO 8846 ignition protection
- Over-the-air firmware updates plus system settings backup and restore
Compatibility and fit
The command center is intended for helms that want lighting control integrated into the display system, with support for Garmin OneHelm-enabled MFDs, Raymarine Axiom, and selected Simrad, B&G, and Lowrance displays. Furuno NavNet TZ Touch3 series support uses an SD card accessory for integration. Lighting compatibility is for Lumishore LUX above-water systems and SMX, THX, and TIX EOS underwater systems.
Installation and setup
Plan for a clean DC power feed within the 10.5 to 31 V range, then route the plug-and-play connections to the lighting system and helm control path used on your boat. Once connected, the system supports light discovery and setup through the control interface, along with brightness adjustment and diagnostic functions that help with commissioning and troubleshooting.
Wi-Fi control can run through the MFD Wi-Fi or a local Wi-Fi network onboard. Firmware can be updated over the air, and settings can be backed up and restored, which is handy after software updates or system changes.
On-board use
This is a good match for boats running multiple lighting zones, where you want quick scene changes at the dock, at anchor, or underway at night. Color cycle and sweep modes are available for compatible lights, and sound-to-light control is supported when you want lighting to react during onboard entertainment.
